Technical data
Recommended bar length cm/inch | 30cm/12″ |
Weight kg 1) | 4.8 |
Sound pressure level dB(A) 2) | 76 |
Sound power level dB(A) 3) | 93 |
Vibration level left/right m/s² 4) | 1.0/1.0 |
STIHL Oilomatic saw chain pitch/type | 1/4″ P PM3 |
Total length cm 5) | 270-390 |
Recommended battery | AP 180 |
1) Excluding battery
2) K-Factor according to Dir. 2006/42/EG = 2.5 (dB(A)
3) K-Factor according to Dir. 2006/42/EG = 2.5 (dB(A)
4) K-Factor according to Dir. 2006/42/EG = 2 m/s²
5) With bar and chain
The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.
